Engineering and programming of process automation

As an independent system supplier, we rely on the common systems from Siemens, depending on customer requirements. These are Simatic S7 or PCS7 for station control. PCS7, WINCC or IFIX are used for the control technology.

RK512 for TIA Portal

We offer you function blocks for data coupling via RK512 to the Siemens S7-1200 and S7-1500 controllers. Thanks to the developed function blocks and a communication processor, the S7-1200 and S7-1500 automation systems are able to communicate directly with an RK512 partner. Additional protocol converters or gateways are not required. This makes it possible to connect existing legacy systems with the newer generation of S7 controllers and simultaneously take over automation tasks without any major additional effort.

Technical data of the function blocks for RK512:

  • Function block for RK512 Master and slave any number of data jobs can be parameterised
  • Supported interfaces RS232, RS422, RS485
  • Can be assigned to several serial interfaces (multiple operation)
  • Interface speeds up to 115.2 kbits/s
  • Large data volumes via RK512 sequence telegrams
  • Evaluation of the block check checksum
  • Simple configuration of the modules
  • Error detection
  • Timeout monitoring
